TRAIL ŘEZNÍK S VELKÝMI KOLY

Monster truck s pocitem sportovního vozu. Opravdu jsme chtěli vytvořit zábavný, všestranný, ale přesto agresivní bike s nízkým zdvihem. Bike s velkými koly a progresivní geometrií, který je doma při celodenním pokořováním trailů.

Geometrie pro 130mm vidlici

Frame Geo (130mm Fork)	S	M	L	XL
A – Head Angle High	67.4°	67.4°	67.4°	67.4°
Head Angle Low	66.8°	66.8°	66.8°	66.8°
B – Seat Tube Angle High	74.3°	74.3°	74.3°	74.3°
Seat Tube Angle Low	73.4°	73.4°	73.4°	73.4°
C – Virtual Top Tube Length	585mm \| 23.03″	606mm \| 23.85″	626mm \| 24.64″	647mm \| 25.47″
D – Seat Tube Length	381mm \| 15.00″	432mm \| 17.00″	470mm \| 18.50″	508mm \| 20.00″
E – Bottom Bracket Height High	338mm \| 13.3″	338mm \| 13.3″	338mm \| 13.3″	338mm \| 13.3″
Bottom Bracket Height Low	331mm \| 13.0″	331mm \| 13.0″	331mm \| 13.0″	331mm \| 13.0″
F – Head Tube Length	90mm \| 3.5″	110mm \| 4.3″	110mm \| 4.3″	120mm \| 4.7″
G – Chain Stay Length High	430mm \| 16.93″	430mm \| 16.93″	430mm \| 16.93″	430mm \| 16.93″
Chain Stay Length High	432mm \| 17.00″	432mm \| 17.00″	432mm \| 17.00″	432mm \| 17.00″
H – Wheel Base High	1119mm \| 44.10″	1142mm \| 44.98″	1162mm \| 45.77″	1184mm \| 46.63″
Wheel Base Low	1120mm \| 44.11″	1143mm \| 45.02″	1163mm \| 45.80″	1185mm \| 46.67″
I – Standover	659mm \| 25.9″	697mm \| 27.4″	715mm \| 28.1″	731mm \| 28.7″
J – Axle to Crown	530.8mm	530.8mm	530.8mm	530.8mm
K – Offset	51mm	51mm	51mm	51mm
Stack	589mm \| 23.2″	608mm \| 23.9″	608mm \| 23.9″	617mm \| 24.3″
Reach	403mm \| 15.9″	419mm \| 16.5″	439mm \| 17.3″	457mm \| 18.0″
Sizing	5’3″ – 5’8″	5’8″ – 6’0″	6’0″ – 6’4″	6’4″

Geometrie pro 120mm vidlici

Frame Geo (120mm Fork)	S	M	L	XL
A – Head Angle High	67.8°	67.8°	67.8°	67.8°
Head Angle Low	67.2°	67.2°	67.2°	67.2°
B – Seat Tube Angle High	74.8°	74.8°	74.8°	74.8°
Seat Tube Angle Low	73.9°	73.9°	73.9°	73.9°
C – Virtual Top Tube Length	585mm \| 23.03″	606mm \| 23.85″	626mm \| 24.64″	647mm \| 25.47″
D – Seat Tube Length	381mm \| 15.00″	432mm \| 17.00″	470mm \| 18.50″	508mm \| 20.00″
E – Bottom Bracket Height High	334mm \| 13.14″	334mm \| 13.14″	334mm \| 13.14″	334mm \| 13.14″
Bottom Bracket Height Low	326mm \| 12.83″	326mm \| 12.83″	326mm \| 12.83″	326mm \| 12.83″
F – Head Tube Length	90mm \| 3.5″	110mm \| 4.3″	110mm \| 4.3″	120mm \| 4.7″
G – Chain Stay Length High	430mm \| 16.93″	430mm \| 16.93″	430mm \| 16.93″	430mm \| 16.93″
Chain Stay Length Low	432mm \| 17.00″	432mm \| 17.00″	432mm \| 17.00″	432mm \| 17.00″
H – Wheel Base High	1115mm \| 43.90″	1139mm \| 44.80″	1158mm \| 45.60″	1180mm \| 46.46″
Wheel Base Low	1116mm \| 43.94″	1140mm \| 44.90″	1159mm \| 45.63″	1181mm \| 46.50″
I – Standover	655mm \| 25.80″	693mm \| 27.28″	710mm \| 27.98″	726mm \| 28.61″
J – Axle to Crown	520.8mm	520.8mm	520.8mm	520.8mm
K – Offset	51mm	51mm	51mm	51mm
Stack	586mm \| 23.07″	604mm \| 23.77″	604mm \| 23.77″	614mm \| 24.17″
Reach	408mm \| 16.06″	424mm \| 16.69″	444mm \| 17.48″	462mm \| 18.18″
Sizing	5’3″ – 5’8″	5’8″ – 6’0″	6’0″ – 6’4″	6’4″

Velikost

Component Sizing	Small	Medium	Large	XLarge
Stem Length	50mm	50mm	50mm	50mm
Stem Rise	5°	5°	5°	5°
Handlebar Rise	25mm	25mm	25mm	25mm
Handlebar Width	750mm	750mm	750mm	750mm
Crank Length	170mm	175mm	175mm	175mm
Sizing	5’3″ – 5’8″	5’8″ – 6’0″	6’0″ – 6’4″	6’4″

Naše vychytávky

ISCG05

Integrated ISCG05 tabs just in case the Narrow/Wide chainring isn’t cutting it.

DELTA SYSTEM

Completely redesigned with a focus on simplicity, weight reduction and strength. We increased lateral frame stiffness with redesigned dog bone links that use integrated forged bosses to connect the linkage and simplify maintenance.

DOWNTUBE PROTECTOR

Molded Rubber Downtube Protector keeps rocks and debris off the plastic and quiets the ride.

THRU AXLE MAIN PIVOT

A 15mm thru axle with 15x24x7 dual row angular contact bearings provide a stiff and durable main pivot.

INTERNAL ROUTING

Internal routing for stealth dropper posts. Rear derailleur and brake routing is cleanly routed under the toptube and the rear derailleur cable is internally routed through the swingarm to keep things tidy.

PLASTIC FANTASTIC

Uni Directional Carbon with One Piece Molded construction from one of the best factories in the business.

RUBBER PROTECTION

Integrated rubber protection for the chainstay and seat stay to keep things peaceful and quiet in the woods.

SAG METER

We added a fancy integrated SAG meter into the non-drive side Delta Link to make suspension set up easy. Push it forward, sit on your bike, adjust air pressure to 30%, then shred.
